Model	SW2-20-OS	SW2-20-HT
Work Capacity
Height	32"	32"
Turntable Diameter	20" Rollout qty 2	20" Rollout qty 2
Load Weight	400 lbs	400 lbs
Floor Space Required
Height	66"	66"
Width	44"	48"
Length: Door Open	87"	87"
Length: Door Closed	67"	81"
Loading Height	27"	27"
Cleaning System
Solution Capacity	90 Gallons	115 Gallons
Pump Motor	7.5 HP	7.5 HP
Pump Output	55 psi@165 gpm	55 psi@165 gpm
Spray Nozzles	34 alternating	34 alternating
Manifold Size	1.50"	1.50"
Filter Screen	695 sq"	1290 sq"
Turntable Drive	Sprocket Driven	Sprocket Driven
Cabinet Construction
Tank Construction (gauge steel)	12	12
Steam Vent	6"	6"
Gas Vent	4"	4"
Heat Source
Electric Heat	15 KW (2) 7.5 KW Elements	15 KW (2) 7.5 KW Elements)
Gas Burner	80,000 BTU	100,000 BTU
Hot Tank Baskets
Dimensions	12"x24"x 11"	21"x30"x11"
Electrical Requirements
7.5 HP Pump Motor 3 Phase	208v 25.3 amps	208v 25.3 amps
7.5 HP Pump Motor 3 Phase	230v 22 amps	230v 22 amps
7.5 HP Pump Motor 3 Phase	460v 11 amps	460v 11 amps
Electric Heat 3 Phase	208v 41.6 amps	208v 41.6 amps
Electric Heat 3 Phase	230v 37.7 amps	230v 37.7 amps
Electric Heat 3 Phase	460v 18.8 amps	460v 18.8 amps
Gas Burner	120v 1 Phase 2.5 amps	120v 1 phase 2.5 amps
Drive Motor	120v 1 phase .60 amps	120v 1 phase .60 amps
Standard Equipment
Low Water Switch	Yes(electric heat)	Yes(electric heat)
Dual 7 Day Timers	Yes	Yes
Digital Temp Controller	Yes	Yes
Dual 20" Diameter Turntables	Yes	Yes
Auto Air Inducer	Yes	Yes
Adjustable Head Rack	Yes	Yes
Options
Electric Heat	460v 17 amps	460v 17 amps
7.5 HP Pump 1 Phase	240v 40 amps	240v 40 amps
Electrical Heater 1 Phase	230v 65.2 amps	230v 65.2 amps
Turntable Basket	20"	20"
Hand Basket	12"x12"x8"	12"x12"x8"
Parts Basket with Lid	12"x12"x5"	12"x12"x5"
Parts Basket with Lid	10"x10"x4"	10"x10"x4"
Oil Skimmer
Boom/Crane Assy with Trolley
Gas Burner Cover
Amperage Saver(Electric Only)
Insulation Package
Shipping Weight	1040 lbs	1320 lbs
