SPECIFICATIONS
Inside Dimensions………………………………................………………………………….……...24”W x 46”L x 22”H
Floor Space Required…….................………………………………………..……………………...40”W x 63”L x 76”H
Air Requirements……….……………………................…………..…………………………....……...80 PSI @ 20 CFM
Electrical Requirements…………………………................………………………………………..……115 V @ 7 AMPS
Window (double strength safety glass)……................……………....……..………………………...……...10” x 24”
Double Fluorescent Lighting………………................…………………....……..……………………..…...24” Fixtures
Cabinet………………………………………………..................……………..…......…..14 Gauge Welded Construction
Gun Control (pistol grip)……………...............……………….………...………………………………………..Foot Valve
Reclaimer Motor……………..………………...............…...………….....………………………..……..1//2 HP 450 CFM
Dust Bag (with zipper for easy clean-out)………………….................…...……….…………………..………………….
Bead Capacity……………………………………………………..............…………………………………………………..20 lbs
Recommended Bead Size………………………………………………………………………..............……..……..AXE 6/1
Shipping Weight………………………………….............………...……………………………………………………...550 lbs
Specifications subject to change without notice
